This part was created using our CNC punching machine. The corners were welded and ground smooth and then this part was sent out for plating per our customer’s specifications.
Details And Specifications
Product Description
Defense Industry Chassis Cover
Capabilities Applied/Processes
Primary:
CNC Punching
CNC Bending
Secondary:
Welding
Grinding
CNC Punching
CNC Bending
Secondary:
Welding
Grinding
Equipment Used to Manufacture Part
Trumpf 1000 CNC Punch, Trumpf 5085 CNC Brake, Lincoln welder
Overall Part Dimensions
Length: 16.00”
Width: 10.00”
Thickness: 2.5”
Width: 10.00”
Thickness: 2.5”
Tightest Tolerances
±.015”
Material Used
CRS
Max Material Finish
63Ra
In Process Testing/Inspection Performed
First Article, Functional testing
Estimated Part Weight
2 lbs.
Industry for Use
Electronic Equipment
Volume
175
Delivery Location
East Coast, USA
Standards Met
Customer supplied print, 2D CAD Drawing,
MIL specifications
ASME Y14.5M-1994
Material certifications
Geometric Tolerancing
Plating Specs
MIL specifications
ASME Y14.5M-1994
Material certifications
Geometric Tolerancing
Plating Specs
Product Name
Perforated Cover
